Commands Listed in Alphabetical Order
Related Commands
DATa:ENCdg, WF
MInpre:BYT_Or, WFMInpre:BN_Fmt, CURVe
Arguments
ASCIi sets the encoding for waveform data transfer to ASCI i format.
BINary sets the encoding for the waveform data transfer to binary format.
Examples
WFMINPRE:ENCDG ASCII specifies that the input waveform data is in ASCII
format.
WFMINPRE:ENCDG? might return WFMINPRE:ENCDG BIN, indicating that the
waveform data is in binary format.
WFMInpre:NR_Pt
This command sets or queries the record length of the input waveform. The query
returns the allocated record length of the input waveform. This is the number
of points in the curve plus any additional NULL values to fill the record. Any
additional input points will be discarded. Valid record lengths are 20, 50, 100,
250, 500, 1000, 2000, and 4000. When using this command to set the record
length of the input waveform and the input value is different from one of the valid
record lengths, the value will be coerced to the next higher valid record length.
An event will then be generated.
Group
Waveform Transfer
Syntax
WFMInpre:NR_Pt <NR1>
WFMInpre:NR_Pt?
Related Commands
CURVe, DATa:STOP, DATa:STARt, DATa:DESTination
Arguments
NR1
This argument is a valid record length. It can be 20, 50, 100, 250, 500, 1000,
2000, and 4000.
Examples
WFMINPRE:NR_PT 2000 sets the record length to 2000.
WFMINPRE:NR_PT? might return WFMINPRE:NR_PT 4000, indicating that the
record length for the input waveform is set to 4000.
DSA/CSA/TDS8X00/B Series Programmer Manual 2-357
