Commands Listed in Alphabetical Order
Related Commands
CH<x>:OFFSet
Arguments
NR3 is the vertical offset in volts of the incoming waveform.
Examples
WFMINPRE:YZERO 5.0E-6 sets the vertical offset of the incoming waveform
to5ĀµV
WFMINPRE:YZERO? might return WFMINPRE:YZERO 1.00000000000E-00 6,
indicating that the vertical offset of the incoming waveform is 1 ĀµV.
WFMOutpre? (Query Only)
This is a query only command that returns the preamble for the outgoing
waveform. This data always corresponds to the previous CURVe? command
(the returned parameters do not necessarily correspond to the current waveform
settings made by the DATa:SOUrce command). A CURVe? command must
precede the WFMOutpre? query to get corresponding header/data information.
Group
Waveform Transfer
Syntax
WFMOutpre?
Related Commands
CURVe, WAVFrm ?
Examples
WFMOUTPRE? might return WFMOUTPRE:ENCDG A SCII;BN_FMT
RI;BYT_OR LSB;BYT_NR 4 ;BIT_NR 32;NR_PT 500; PT_FMT Y;XINCR
500.00000000000E-012;XZER O 18
.00000000008E-009;XUNIT
"";YMULT 0.100000000000;XMULT 500.00000000000E-012;XOFF
20.50000000008E-009;YZERO 0.000000000000; YSCALE
232.83064365432E-012;YOFF 0;YUNIT "";WFID "PULS E TEST,
100.0MV/DIV, 500.0PS/DIV, 500 POINTS, SAMPLE MODE ";WFMLABEL
"PULSE TEST"
.
WFMOutpre:BIT_Nr? (Query Only)
This query only command returns the number of bits (width) per waveform point
of the waveform to b e transferred from the instrument.
NOTE. This instrument supports only a 32-bit format.
2-364 DSA/CSA/TDS8X00/B Series Programmer Manual
