Commands Listed in Alphabetical Order
Group
Waveform Trans
fer
Syntax
WFMOutpre:BIT_Nr?
Related Commands
WFMOutpre:BYT_Nr?
Examples
WFMOUTPRE:BIT_NR? might return WFMOUTPRE:BIT_NR 32, indicating that
there are 32 bits per waveform point.
WFMOutpre:BN_Fmt
This command sets or queries the format of the binary data encoding of the
waveform to be transferred from the instrument. Sending this command will
coerce DATa:ENCdg to a corresponding setting based on binary format and order.
Group
Waveform Transfer
Syntax
WFMOutpre:BN_Fmt {RI | FP}
WFMOutpre:BN_Fmt?
Related Commands
DATa:ENCdg, WFMOutpre:BYT_Or, WFMOutpre:ENCdg
Arguments
RI specifies signed integer data-point representation.
FP specifies floating-point data-point representation.
Examples
WFMOUTPRE:BN_FMT RI specifies that the binary waveform data are signed
integer data points.
WFMOUTPRE:BN_FMT? might return WFMPRE:BN_FMT FP, indicating that the
current waveform data format is floating point binary.
WFMOutpre:BYT_Nr? (Query Only)
This query only command returns the byte width for the waveform to be
transferred from the instrument.
NOTE. This instrument supports only 4-byte data widths.
DSA/CSA/TDS8X00/B Series Programmer Manual 2-365
