Commands Listed in Alphabetical Order
Arguments
EDGE sets subse
quent autoset commands to configure the instrument to
display a rising edge of the signal connected to the currently selected channel
in the center 20% of the graticule.
PERIod sets subsequent autoset commands to configure the instrument to
display 2 to 3 periods of the signal connected to the currently selected channel
centered in the graticule.
EYE sets subsequent autoset commands to configure the instrumen t to display
one bit (two eye crossings) horizontally centered across approximately 70%
of the graticule (7 divisions) and vertically centered across approximately
60% of the graticule (6 divisions). Use the Eye argument for N
RZ waveforms.
RZ sets subsequent autoset commands to configure the instrument to display
one bit (two rising edges) horizontally centered across approximately 60%
of the graticule (6 divisions) and vertically centered across approximately
50% of the graticule (5 divisions).
TDR sets subsequent autoset commands to configure the instrumen t to display
the first significant reflection at the third horizontal division. If the Display
Incident Edge option is on, the incident edge is placed at the one-half
horizontal division (from left edge). If the Displ
ay Incident Edge is off,
the incident edge is placed one horizontal division off the left edge of the
screen. If no significant reflections are located, the incident edge is placed
at the one-half horizontal division (from left edge) regardless of the Display
Incident Edge setting.
Examples
AUTOSET:TYPE EDGE sets the default Autoset m ode to EDGE.
AUTOSET:TYPE? might return AUTOSET:TYPE RZ, indicating that the default
AutosetmodeisRZ.
AUTOSet:UNDO (No Query Form)
This command (no query form) returns the parameters changed by an AUTOSet
command to their previous states. This command is invalidated the first time you
modify any instrument state parameter.
Group
Miscellaneous
Syntax
AUTOSet:UNDO
Related Commands
AUTOSet
Examples
AUTOSET:UNDO returns the parameters to their previous sta tes,
2-70 DSA/CSA/TDS8X00/B Series Programmer Manual
