Tektronix Keithley DMM7510 User Manual

Model DMM7510
7½ Digit Multimeter User's Manual Section 2: Front-
panel overview
DMM7510-900-01 Rev. C / September 2019 2-9
FUNCTIONS swipe screen
The FUNCTIONS swipe screen highlights the selected measure function and allows you to select a
different function.
Figure 6: FUNCTIONS swipe screen
SETTINGS swipe screen
The SETTINGS swipe screen gives you front-panel access to some instrument settings for the
selected measure function. It shows you the present settings and allows you to change them. The
available settings depend on which measure function is active.
Figure 7: SETTINGS swipe screen
To disable or enable a setting, select the box next to the setting so that it shows an X (disabled) or a
check mark (enabled).
For descriptions of the settings, select a button, then press the HELP key.
