Tektronix MDO3000 Series Technical Reference

Specifications
Table 6: Trigger specifications (cont.)
Characteristic Description
Data Trigger: Tx Data, Rx Data
Trigger On: Tx Start Bit
Rx Start Bit
Tx End of Pa cket
Rx End of Packet
Tx Data
Rx Data
Tx Parity Error
Rx P a rity Error
RS-232/422/
485/UART
(Requires a
MDO3COMP
app. module)
Maximum Data Rate:
10 Mb/s
Data Trigger:
1 to 8 bytes of user specified data, including qualifiers of equal
to (=), not equal to (<>), less than (<), greater than (>), less than
or equal to (<=), greater than or equal to (>=)
Trigger On: Start of Frame
Type of Frame
Identifier, Data
Identifier and Data
End of Frame
Missing Ack
Bit Stuffing Error
Frame Type:
Data, Remote, Error, Overload
Identifier: Standard (11 bit) and Extended (29 bit) identifiers
CAN
(Requires an
MDO3AUTO
app. module)
Maximum Data Rate:
1Mb/s
Data Trigger:
1 to 8 Bytes of user-specified data, including qualifiers of equal
to (=), not equal to (<>), less than (<), greater than (>), less than
or equal to (<=), greater than or equal to (>=)
Trigger On : Sync
Identifier
Data
Identifier & Data
Wakeup Frame
Sleep Frame
Error
LIN
(Requires a
MDO3AUTO
app. module)
Maximum Data Rate:
1 Mb/s (by LIN definition, 20 kbit/s)
MDO3000 Series S pecifications and Performance Verification 21
