Tektronix MDO3000 Series Technical Reference

Specifications
Table 6: Trigger specifications (cont.)
Characteristic D escription
Rise/fall time trigger,
delta time range
4 ns to 8 s econds
Glitch, pulse-width,
or time-qualified runt
trigger,
time range
4 ns to 8 s econds
Trigger after events, minimum pulse width, typical:
5
1 / (2 X Rated Instrument Bandwidth)
Trigger after events, maximum event frequency, typical:
5
[Rated Instrument Bandwidth] or
500 MHz, whichever is lower
Minimum time between arm and trigger 8 ns
B trigger after time, time range:
8nsto8s
B trigger
(A/B sequence
trigger), time range
B trigger after events, event range:
1 to 4,000,000
Standard serial bus
interface triggers
Maximum serial trigger bits: 128 bits
Address Triggering:
7 and 10 bit user specified address, as well as General Call,
START byte, HS-mode, EEPROM, and CBUS
Data Trigger:
1 to 5 bytes of user specified data
Trigger On: Start
Repeated Start
Stop, Missing Ack
Address
Data
Address and Data
I
2
C
(Requires an
MDO3EMBD
app. module)
Maximum Data Rate:
10 Mb/s
Data Trigger:
1 to 16 bytes of user specified data
Trigger On: SS Active
MOSI
MISO
MOSI and MISO
SPI
(Requires an
MDO3EMBD
app. module)
Maximum Data Rate:
10 Mb/s
20 MDO3000 Series Specifications and Performance Verification
