Command Groups
Table 2-41: Trigger Commands (cont.)
Command
Description
TRIGger:A:BUS:B<x>:FLEXray:E OFTYPE This command speci fies the end of file type (static, dynamic or any) when
triggering on the FlexRay bus EOF field.
TRIGger:A:BUS:B<x>:FLEXray:ERRTYPE This command specifies the error type when triggering o n the FlexRay bus
signal.
TRIGger:A:BUS:B<x>:FLEXray:FRAMEID:
HIVALue
This command specifies the high value when triggering on the FlexRay bus
frame ID field.
TRIGger:A:BUS:B<x>:FLEXray:FRAMEID:
QUALifier
This command specifies the qualifier to use when triggering on the FlexRay
bus frame ID field.
TRIGger:A:BUS:B<x>:FLEXray:FRAMEID:VALue This command speci fi es the low value when triggering on the FlexRay bus
frame ID field.
TRIGger:A:BUS:B<x>:FLEXray:FRAMEType This command specifies the frame type (normal, payload, null, sync or startup)
when triggering on the FlexRay bus signal.
TRIGger:A:BUS:B<x>:FLEX ray:HEADER:CRC This command specifies the CRC portion of the binary header string when
triggering on the FlexRay bus signal.
TRIGger:A:BUS:B<x>:FLEXray:HEADER:
CYCLEcount
This command specifies the cycle count portion of the binary header string
when triggering on the FlexRay bus header.
TRIGger:A:BUS:B<x>:FLEXray:HEADER:
FRAMEID
This command specifies the frame ID portion of the binary header string when
triggering on the FlexRay bus header.
TRIGger:A:BUS :B<x>:FLEX ray:HEADER:INDBits This command specifies the indicator bits portion of the binary header string
when triggering on the FlexRay bus header.
TRIGger:A:BUS:B<x>:FLEXray:HEADER:
PAYLength
This command specifies the payload length portion of the binary header string
when triggering on the FlexRay bus header.
TRIGger:A:BUS :B<x>:I2C:ADDRess:MODe This command specifies the I2C address mode to 7 or 10-bit
TRIGger:A:BUS:B<x>:I2C:ADDRess:TYPe This command speci fies the I2C address type to USER
TRIGger:A:BUS:B<x>:I2C:ADDRess:VALue This command speci fies the b inary address string used for the I2C trigger
TRIGger:A:BUS :B<x>:I2C:C ON Dition This command specifies the trigger condition for I2C trigger
TRIGger:A:BUS :B<x>:I2C:D ATa:DIRection This command specifies the I2C trigger condition valid on a READ, WRITE,
or either
TRIGger:A:BUS :B<x>:I2C:D ATa:SIZe This command specifies the length of the data string in bytes to be used for
I2C trigger
TRIGger:A:BUS:B<x>:I2C:DATa:VALue This command specifies the binary data string used for I2C triggering
TRIGger:A:BUS :B<x>:LIN:C ON Dition This command specifies the trigger condition for LIN
TRIGger:A:BUS:B<x>:LIN:DATa:HIVALue This command specifies the b inary data string to be used for LIN trigger
TRIGger:A:BUS:B<x>:LIN:D ATa:QUALifier This command speci fi es the LIN data qualifier
TRIGger:A:BUS :B<x>:LIN:D ATa:SIZe This command specifies the length of the data string in bytes to be used for
LIN trigger
TRIGger:A:BUS:B<x>:LIN:DATa:VALue This command specifies the binary data string
TRIGger:A:BUS:B<x>:LIN:ERRTYPE This command specifies the error type
TRIGger:A:BUS :B<x>:LIN:ID entifier:VALue This command specifies the binary address string used for LIN trigger
2-84 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
