Tektronix MDO3000 Series Program Manual

Command Groups
Table 2-36: Power Commands (cont.)
Command Description
POWer:SWLoss:GATe:TURNON This command specifies the gate turn on level for switching loss power measurements
POWer:SWLoss:NUMCYCles? Returns the number of cycles counted for the switching loss calculation
POWer:SWLoss:RDSon This command specifies RDSON value for use in switching loss calculations when the
conduction calculation method is RDSON
POWer:SWLoss:REFLevel:
ABSolute:GATE Mid
This command specifies the mid voltage reference level used in switching loss power
measurements in v olts
POWer:SWLoss:REFLevel:
ABSolute:LOWCurrent
This command specifies the low current reference level used in switching loss power
measurements in amperes
POWer:SWLoss:REFLevel:
ABSolute:LOWVoltage
This command speci fies the low voltage reference level used in switching loss power
measurements in v olts
POWer:SWLoss:REFLevel:
PERCent:GATEMid
This command specifies the mid voltage reference level used in switching loss power
measurements in percentage
POWer:SWLoss:REFLevel:
PERCent:LOWCurrent
This command specifies the low current reference level used in switching loss power
measurements in percentage
POWer:SWLoss:REFLevel:
PERCent:LOWVoltage
This command speci fies the low voltage reference level used in switching loss power
measurements in percentage
POWer:SWLoss:TOFF:ENERGY:
MAX?
Returns the maximum Toff energy switching loss calculation
POWer:SWLoss:TOFF:ENERGY:
MEAN?
Returns the mean Toff energy switching loss calculation
POWer:SWLoss:TOFF:ENERGY:
MIN?
Returns the minimum Toff energy switching loss calculation
POWer:SWLoss:TOFF:POWer:
MAX?
Returns the maximum Toff power switching loss calculation
POWer:SWLoss:TOFF:POWer:
MEAN?
Returns the mean Toff power switching loss calculation
POWer:SWLoss:TOFF:POWer:MIN? Returns the minimum Toff power switching loss calculation
POWer:SWLoss:TON:ENERGY:
MAX?
Returns the maximum Ton energy switching loss calculation
POWer:SWLoss:TON:ENERGY:
MEAN?
Returns the mean Ton energy switching loss calculation
POWer:SWLoss:TON:ENERGY:
MIN?
Returns the minimum Ton energy switching loss calculation
POWer:SWLoss:TON:POWer:MAX?
Returns the maximum Ton power switching loss calculation
POWer:SWLoss:TON:POWer:
MEAN?
Returns the mean Ton power switching loss calculation
POWer:SWLoss:TON:POWer:MIN?
Returns the minimum Ton power switching loss calculation
POWer:SWLoss:TOTal:ENERGY:
MAX?
Returns the maximum total energy switching loss calculation
POWer:SWLoss:TOTal:ENERGY:
MEAN?
Returns the mean total energy switching loss calculation
2-46 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
