TRIGger:A:BU
S:B<x>:ETHERnet:MAC:ADDRess:DESTination:VALue
When the Ethernet trigger condition is set to MACADDress, this command
specifies the 48–bit MAC destination address that is to be used in the trigger
(along with t
he source address value). The default is all X’s (don’t care).
B<x> is
the bus number B1-B4.
NOTE. MAC Addresses are 48–bit values such as 08:00:11:1E:C9:AE hex.
Conditions
This command requires a DPO4ENET application module for DPO/MSO4000B
and MDO4000/B/C models.
Group
Trigger
Syntax
TRIGger:A:BUS:B<x>:ETHERnet:MAC:ADDRes s:DESTination:VALue
<QString>
TRIGger:A:BUS:B<x>:ETHERnet:MAC:ADDRes s:DESTination:VALue?
Related Commands
TRIGger:A:BUS:B<x>:
ETHERnet:CONDition
TRIGger:A:BUS:B<x>:ETHERnet:MAC:ADDRess:SOUrce:VALue
Arguments
QString is a quoted string of up to 48 characters where the allowable characters
are 0, 1, and X. The bits specified in the quoted string replace the least significant
bits, leaving any unspecified upper bits unchanged.
Examples
TRIGger:A:BUS:B1:ETHERnet:MAC:ADDRess: DESTination:VALue
”XXXXXXXXXX01010111111100000001111010101010101000” would set the
MAC destination address to trigger on to XX:35:FC:07:AA:C8 hex.
TRIGger:A:BUS:B1:ETHERnet:MAC:ADDRess: DESTination:VALue?
might return ”XXXXXXXXXX01010111111100000001111010101010101000”.
TRIGger:A:BUS:B<x>:ETHERnet:MAC:ADDRess:SOUrce:VALue
When the Ethernet trigger condition is set toMACADDress, this command specifies
the 48–bit MAC source address value that is to be used in the trigger (along
with the destination address value). The default is all X’s (don’t care).
B<x> is
the bus number B1-B4.
NOTE. MAC Addresses are 48–bit values such as 08:00:11:1E:C9:AE hex.
MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual 2-801
