Acquire the Sign
al
5. Optionally, push B1 Label to edit the label for
the bus. (See page 51, Labeling Channels
and Buses.)
Bus B1
Parallel
Define
Inputs
Thresholds B1 Label
Parallel
Bus
Display
Event
Table
6. Push Bus Display and use the side-bezel
menu to defin
e how to display the parallel or
serial bus.
Bus
Depending on the bus, use the side-bezel
menu or the
knobs to set the number format.
Bus and
Wave-
forms
Hex
Binary
ASCII
7. Push E vent Table and select On to display a
list of b
us packets with timestamps.
Event
Table
On |Off
Save
Event
Table
For a cl
ocked parallel bus, the table lists the
value of the bus at each clock edge. For
an unclocked parallel bus, the table lists the
value
of the bus whenever any one of its bits
changes.
The Event Table lists bytes, words, or
packe
ts, depending on the bus type.
8. Push
Save Event Table to save the event
table data in a .csv (spreadsheet) format on
the currently selected storage device.
MDO4000 Series Oscilloscopes User Manual 63
