Tektronix MDO4104 User Manual

Specifications
Table 1: A nalog signal acquisition system specifications (cont.)
Characteristic Description
1M 300 V
RMS
at the BNC
Installation Category II
Derate at 20 dB/decade between 4.5 MHz and 45 MHz
Derate 14 dB/decade between 45 MHz and 450 MHz
Above 450 MHz, 5 V
RMS
.
Maximum peak input voltage at the BNC, ±424 V
250 K 75 V
RMS
at the B NC
Installation Category II
Derate at 20 dB/decade between 1.3 MHz and 13 MHz
Derate 10 dB/decade between 13 MHz and 130 MHz
Above 130 MHz, 5 V
RMS
.
Maximum peak input voltage at the BNC, ±106 V
Maximum input
voltage
50  5V
RMS
with peaks ±20 V (Duty Factor  6.25%)
Overvoltage trip is intended to protect against overloads that might damage
termination resistors. A sufficiently large impulse might cause damage
regardless of the overvoltage protection circuitry because of the finite time
required to detect and respond.
DC Balance
0.1 div with the i nput DC coupled, set to 50  termination, and input terminated with 50  BNC terminator
0.2 div at 1 mV/div with the input DC coupled, set to 50  termination, and input terminated with 50 
BNC terminator
0.2 div with the input DC coupled, set to 1 M  termination, and input terminated with 50  BNC terminator
Number of digitized
bits
8bits
Displayed vertically with 25 digitization levels (DL) per division, 10.24 divisions dynamic range.
"DL" is the abbreviation for "digitization level." A DL is the smallest voltage level change that can be
resolved by an 8-bit A-D Converter. This value is also known as the least significant bit (LSB).
1MΩ 1 m V/div to 10 V/div in a 1-2-5 sequenceSensitivity range
(coarse)
50 Ω 1 mV/div to 1 V/div in a 1-2-5 sequence
1 m V/div to 5 V/div < –50% to > + 50% of selected setting
10 V/div < –50% to 0%
1MΩ
Allows continuous adjustment from 1 mV/div to 10 V/div
1 mV/div to 500 mV/div < –50% to > +50% of selected setting
1 V/div < –50% to 0%
Sensitivity range (fine)
50 Ω
Allows continuous adjustment from 1 mV/div to 1 V/div
Sensitivity resolution
(fine), typical
1% of current setting
2 MDO4000 Series Specifications and Performance Verification
