Tektronix MDO4104 - Triggering System Specifications

Specifications
Triggering Sy
stem Specifications
The following table shows the trigger specifications for analog and digital
channels on the MDO4000 Series oscilloscopes. These specifications do not
applytotheR
F input channel.
NOTE. For RF, please see the analog to RF trigger skew specification. (See
page 17, RF Input Specifications.)
Table 4: Trigger specifications
Characteristic Description
MDO4104-X 1 GHz
MDO4054-X
500 MHz
MDO4034-3
350 MHz
Trigger bandwidth, Edge, typical
MDO4014-3
100 MHz
MDO4104-X 1 GHz
MDO4054-X
500 MHz
MDO4034-3
350 MHz
Trigger bandwidth, Pulse and Logic,
typical
MDO4014-3
100 MHz
Model Trigger
Source
Sensitivity
MDO4104-X
Any input
channel
50  path:
0.40 div from D C to 50 MHz, increasing to
1 div at oscilloscope bandwidth
MDO4054-X, MDO4034-3,
MDO4014-3
Any input
channel
50  path:
1 m V/div to 4.98 mV/div — 0.75 div from
DC to 50 MHz, increasing to 1.3 div at
oscilloscope bandwidth.
5 mV/div — 0.40 div from DC to
50 MHz, increasing to 1 div at oscilloscope
bandwidth.
All models Any input
channel
1M path:
1 mV/div to 4 .98 mV/div – 0.75 div from
DC to 50 MHz, increasing to 1.3 div at
oscilloscope bandwidth.
5 mV/div – 0.40 div from DC to 50 M Hz,
increasing to 1 div at oscilloscope
bandwidth.
Edge-type trigger sensitivity, DC
coupled, typical
All models Line Fixed
Trigger jitter, typical
10 ps
RMS
for edge-type trigger
100 ps
RMS
for non edge-type trigger modes
10 MDO4000 Series Specifications and Performance Verification
