Specications
Ta ble 4: Trigger specications (cont.)
Characteristic Description
Trigger Coupling Typical Sensitivity
AC Coupling 1 div for frequencies above 45 Hz.
Attenuates signals below 45 Hz.
NOISE R EJ 2.5 times the DC-coupled limits
HF REJ
1.0 times the DC-coupled limits from DC to 5 0 kHz.
Attenuates signals above 50 kHz
Edge-type trigger sensitivity, not DC
coupled, typical
LF REJ
1.5 times the DC-coupled limits for frequencies above
50 kHz. Attenuates signals below 50 kHz
Video-type trigger formats and eld
rates
Triggers from negative sync composite video, eld 1, or eld 2 for interlaced systems, o n any
eld, specic line, or any line for interlaced or noninterlaced systems. Supported systems
include NTSC, PAL, and SE CAM.
Delayed and main trigger
Source Sensitivity
Video-type trigger sensitivity, typical
Any input channel
0.6 to 2.5 divisions of video sync tip
Lowest frequency for successful
operation of "Set Level to 50% "
function, typical
45 Hz
Logic-type or logic qualied trigger
or events-delay sensitivities, DC
coupled, typical
1.0 division from DC to maximum bandwidth
Pulse-type runt trigger sensitivities,
typical
1.0 division from DC to maximum bandwidth
Pulse-type trigger width a nd glitch
sensitivities, typical
1.0 division
For all vertical settings, the minimums are:
Trigger type Pulse width Re-arm time Time between channels
Logic Not applicable 2 ns 1 ns
Time Qualied Logic
4ns 2ns 1ns
Logic-type triggering, minimum logic
or rearm time, typical
For logic, the time between channels refers to the length of time a logic s tate derived from
more than one channel must exist to be recognized. For events, the time is the minimum time
between a main and delayed event that will be recognized if more than one channel is used.
For all vertical settings, the minimums are:
Clock active Clock inactive
User hold time + 2.5 ns 2 ns
Minimum clock pulse widths for
setup/hold time violation trigger,
typical
An active pulse width is the width of the clock pulse from its active edge (as dened in the
Clock Edge lower-bezel menu item) to its inactive edge. An inactive pulse width is the width
of the pulse from its inactive edge to its active edge.
The user hold time is the number selected by the user.
MDO4000 Series Specications and Performance Verication 11
