Specifications
Time Base Syst
em Specifications
The following table shows the horizontal and acquisition system specifications
for the MDO4000 Series oscilloscopes.
Table 2: Tim
e base system specifications
Characteristic Description
MDO4104-X 2.5 S/s – 5 GS/s (1 – 2 analog channels enabled)
2.5 S/s – 2.5 GS/s (3 – 4 analog channels enabled)
Sample-rate range
MDO4054-X, MDO4034-3,
MDO4014-
3
2.5 S/s – 2.5 GS/s
Record Length Range 20 M, 10 M, 1 M, 100 k, 10 k, 1 k
Instrument 1 k 10 k 100 k – 20 M
MDO4104-X (2 channels
enabled)
400 ps – 4
0s
400 ps – 4
00 s
400 ps – 1
,000 s
Seconds/Division range
MDO4104-X (4 channels
enable
d),
MDO4054-X, MDO4034-3,
MDO4014-3
1 ns – 40 s 1 ns – 400 s 1 ns – 1,000 s
Maximum triggered acquisition
rate
> 50,000 wfm/s
Aperture Uncertainty
(3 ps + 0.1 ppm × record duration)
RMS
, for records having 1 minute duration
Long-term sample rate and
delay time accuracy
±5 ppm over any 1mstimeinterval
