Specifications
Table 1: Analog signal acquisition system specifications (cont.)
RMS noise (mV)
Model Bandwidth limit
1M 50
Full Bandwidth
(300 V + 8.0% of
Volts/div setting)
(75 V + 6.0% of
Volts/div setting)
250 MHz bandwidth
(100 V + 5.0% of
Volts/div setting)
(50 V + 4.0% of
Volts/div setting)
MDO4104-X
20 MHz bandwidth
(100 V + 5.0% of
Volts/div setting)
(50 V + 4.0% of
Volts/div setting)
Full Bandwidth
(130 V + 8.0% of
Volts/div setting)
(130 V + 8.0% of
Volts/div setting)
250 MHz bandwidth
(except MDO4014-3)
(100 V + 6.0% of
Volts/div setting)
(100 V + 6.0% of
Volts/div setting)
Random Noise
,
Sample Acquisition
Mode
MDO4054-X,
MDO4034-3,
MDO4014-3
20 MHz bandwidth
(100 V + 4.0% of
Volts/div setting)
(100 V + 4.0% of
Volts/div setting)
Delay between
channels, full
bandwidth, typical
100 ps between any two analog or digital channels with input impedance set to 50 , DC coupling,
with equal volts/division setting or above 10 mV/div
All settings in the instrument can be manually time aligned using the Probe Deskew function from –125 ns
to +125 ns with a resolution of 20 ps
This specification does not pertain to the RF channel. For RF channel delay, see the R F Input Specifications.
Deskew range
–125 ns to +125 ns with a resolution of 20 ps
Crosstalk (channel
isolation), typical
100:1 at 100 MHz and 30:1 at >100 MHz up to the rated bandwidth for any two channels having
equal Volts/Div settings
TekVPI Interface The probe interface allows installing, powering, compensating, and controlling a wide range of probes
offering a variety of features.
The i nterface is available on all front panel inputs. (RF channel requires TPA-N-VPI adapter.)
Total probe power
FiveTektronix VPI-compliant probe interfaces (one per channel). (RF channel requires T PA-N-VPI adapter.)
50 W maximum internal probe power (total for all 5 V PI ports)
Voltage Max Amperage Voltage Tolerance
5V
50 mA (250 mW) ±5%
Probe power per
channel
12 V
2 A (24 W) ±10%
MDO4000 Series Specifications and Performance Verification 7
