Specications
Table 1: A nalog signal acquisition system specications (cont.)
Upper frequency limit,
20 MHz bandwidth
limited, typical
20 MHz, ±20%, all models
The formula is calculated by measuring -3 dB bandwidth of the oscilloscope. The formula accounts for the
rise time contribution of the oscilloscope independent of the rise time of the signal source.
Model
50
1 mV/div to
1.99 mV/div
50
2mV/divto
4.99 mV/div
50
5mV/divto1V/div
MDO4104-X
2 ns 1 ns 350 ps
MDO4054-X
2 ns 1 ns 700 ps
MDO4034-3
2ns 1ns 1ns
MDO4014-3
3.5 ns 3.5 ns 3.5 ns
Model TPP1000 probe
10 mV/div to
19.9 mV/div
TPP1000 probe
20 mV/div to
49.8 mV/div
TPP1000 probe
50 mV/div to 10 V/div
MDO4104-X
2 ns 1 ns 350 ps
MDO4054-X
2 ns 1 ns 700 ps
MDO4034-3
2ns 1ns 1ns
MDO4014-3
3.5 ns 3.5 ns 3.5 ns
Model TPP0500 probe
10 mV/div to
19.9 mV/div
TPP0500 probe
20 mV/div to
49.8 mV/div
TPP0500 probe
50 mV/div to 10 V/div
MDO4104-X
2 ns 1 ns 700 ps
MDO4054-X
2 ns 1 ns 700 ps
MDO4034-3
2ns 1ns 1ns
Calculated rise time at
0.350/BW = t
r
,typical
MDO4014-3
3.5 ns 3.5 ns 3.5 ns
Model (Sample Rate Maximum)
Minimum pulse width
MDO4104-X (2 c hannels enabled)
>800 ps
Peak Detect or
Envelope mode pulse
response, typical
MDO4104-X ( 3 channels enabled),
MDO4054-X, MDO4034-3, MDO4014-3
>1.6 ns
6 MDO4000 Series Specications and Performance Verication
