Specifications
Table 1: Analog signal acquisition system specifications (cont.)
Characteristic Description
Analog bandwidth
selections
MDO4104-6, MDO4104-3, MDO 4054-6, MDO4054-3, MDO4034-3: 20 MHz, 250 MHz, and Full
MDO4014-3: 20 MHz and Full
These limits are for ambient temperature of 30°C and the bandwidth selection set to FULL. R educe the
upper bandwidth frequency by 1% for each °C above 30°C
Volts/Div setting
Bandwidth
5 mV/div — 1 V/div DC to 1.00 GHz
2 mV/div — 4.98 mV/div DC to 350 MHz
MDO4104-X
1 mV/div — 1.99 mV/div DC to 175 MHz
5 mV/div — 1 V/div DC to 500 MHz
2 mV/div — 4.98 mV/div DC to 350 MHz
MDO4054-X
1 mV/div — 1.99 mV/div DC to 175 MHz
2 mV/div — 1 V/div DC to 350 MHzMDO4034-3
1 mV/div — 1.99 mV/div DC to 175 MHz
50 Ω
MDO4014-3 1 mV/div — 1 V/div DC to 100 MHz
5 mV/div — 10 V/div DC to 500 MHz
2 mV/div — 4.98 mV/div DC to 350 MHz
MDO4104-X
1 mV/div — 1.99 mV/div DC to 175 MHz
5 mV/div — 10 V/div DC to 500 MHz
2 mV/div — 4.98 mV/div DC to 350 MHz
MDO4054-X
1 mV/div — 1.99 mV/div DC to 175 MHz
2 mV/div — 10 V/div DC to 350 MHzMDO4034-3
1 mV/div — 1.99 mV/div DC to 175 MHz
1MΩ,typical
MDO4014-3 1 mV/div — 10 V/div DC to 100 MHz
50 mV/div — 100 V/div DC to 1 GHz
20 mV/div — 49.8 m V/div DC to 350 MHz
MDO4104-X
(TPP1000
probe)
10 mV/div — 19.9 m V/div DC to 175 MHz
50 mV/div — 100 V/div DC to 500 MHz
20 mV/div — 49.8 m V/div DC to 350 MHz
MDO4054-X
(TPP0500
probe)
10 mV/div — 19.9 m V/div DC to 175 MHz
20 mV/div — 100 V/div DC to 350 MHzMDO4034-3
(TPP0500)
10 mV/div — 19.9 m V/div DC to 175 MHz
Analog
bandwidth, DC
coupled
With
TPPXX00
10X probes,
typical
MDO4014-3
(TPP0500)
10 mV/div — 100 V/div DC to 100 MHz
Lower frequency limit,
AC coupled, typical
< 10 Hz when AC, 1 M coupled
The AC coupled lower frequency limits are reduced by a factor of 10 when 10X passive probes are used.
Upper frequency limit,
250 MHz bandwidth
limited, typical
250 MHz, ±20%, all models except MDO4014-3
MDO4000 Series Specifications and Performance Verification 5
