Specifications
Table 1: A nalog signal acquisition system specifications (cont.)
Characteristic Description
Measurement type
DC Accuracy (in volts)
Any sample
±[DC gain accuracy × | reading – (offset –
position) | + Offset Accuracy + 0.15 div + 0.6 mV]
Refer to DC Gain Accuracy for temperature
derating information.
Delta volts between any two samples acquired
with the same oscilloscope setup and ambient
conditions
±[DC gain accuracy × | reading | + 0.15 div +
1.2 mV]
Refer to DC Gain Accuracy for temperature
derating information.
DC voltage
measurement
accuracy
Sample acquisition
mode, typical
Offset, position, and the constant offset term must be converted to volts by multiplying by the appropriate
volts/div term.
4 MDO4000 Series Specifications and Performance Verification
