Tektronix MDO4104 User Manual

Performance Ve ri fi cation
DC Gain Accuracy
Performance checks Bandwidth Vertical scale Low limit Test result High limit
MDO4104-3, MDO4104-6
1 m V/div -2.0% 2.0%
2 m V/div -1.5% 1.5%
5 m V/div -1.5% 1.5%
10 mV/div -1.5% 1.5%
20 mV/div -1.5% 1.5%
49.8 mV/div -3.0% 3.0%
50 mV/div -1.5% 1.5%
100 mV/div -1.5% 1.5%
200 mV/div -1.5% 1.5%
500 mV/div -1.5% 1.5%
20 MHz
1 V/div -1.5% 1.5%
250 M
Hz
20 mV/div -1.5% 1.5%
Channel 3
DC Gain Accuracy,
0 V offset, 0
Vvertical
position, 50 
Full
20 mV/div -1.5% 1.5%
1 m V/div -2.0% 2.0%
2 m V/div -1.5% 1.5%
5 m V/div -1.5% 1.5%
10 mV/div -1.5% 1.5%
20 mV/div -1.5% 1.5%
49.8 mV/div -3.0% 3.0%
50 mV/div -1.5% 1.5%
100 mV/div -1.5% 1.5%
200 mV/div -1.5% 1.5%
500 mV/div -1.5% 1.5%
20 M
Hz
1 V/div -1.5% 1.5%
250 MHz
20 mV/div -1.5% 1.5%
Channel 4
DC Gain Accuracy,
0V
offset, 0 V vertical
position, 50 
Full
20 mV/div -1.5% 1.5%
MDO4000 Series Specifications and Performance Verification 35
