Tektronix MDO4104 User Manual

Performance Verification
DC Offset Accuracy
Performance checks Vertical scale Vertical offset
1
Low limit Test result High limit
All models:
1mV/div
900 mV 895.3 mV 904.7 mV
1mV/div
-900 mV -904.7 mV -895.3 mV
100 mV /div
5.0 V 4.965 V 5.035 V
Channel 1
DC Offset Accuracy,
20 MHz BW, 50 
100 mV /div
-5.0 V -5.035 V -4.965 V
1mV/div
900 mV 895.3 mV 904.7 mV
1mV/div
-900 mV -904.7 mV -895.3 mV
100 mV/d
iv
9.0 V 8.935 V 9.065 V
100 mV/
div
- 9.0 V -9.065 V -8.935 V
500 mV/
div
9.0 V 8.855 V 9.145 V
500 mV
/div
- 9.0 V -9.145 V -8.855 V
1.01 V
/div
99.5 V 98.80 V 100.2 V
1.01
V/div
-99.5 V -100.2 V -98.80 V
3V/d
iv
99.5 V 98.40 V 100.6 V
3V/
div
-99.5 V -100.6 V -98.4 V
5V
/div
99.5 V 98.00 V 101.0 V
Channel 1
DC Offset Accuracy,
20 MHz BW, 1 M
5V
/div
-99.5 V -101.0 V -98.00 V
1
mV/div
900 mV 895.3 mV 904.7 mV
1
mV/div
-900 mV -904.7 mV -895.3 mV
100 mV /div
5.0 V 4.965 V 5.035 V
C
hannel 2
DC Offset Accuracy,
20 MHz BW, 50 
100 mV /div
-5.0 V -5.035 V -4.965 V
1mV/div
900 mV 895.3 mV 904.7 mV
1mV/div
-900 mV -904.7 mV -895.3 mV
100 mV /div
9.0 V 8.935 V 9.065 V
100 mV /div
-9.0 V -9.065 V -8.935 V
500 mV /div
9.0 V 8.855 V 9.145 V
500 mV /div
- 9.0 V -9.145 V -8.855 V
1.01 V/div
99.5 V 98.80 V 100.2 V
1.01 V/div
-99.5 V -100.2 V -98.80 V
3V/div
99.5 V 98.40 V 100.6 V
3V/div
-99.5 V -100.6 V -98.4 V
5V/div
99.5 V 98.00 V 101.0 V
Channel 2
DC Offset Accuracy,
20 MHz BW, 1 M
5V/div
-99.5 V -101.0 V -98.00 V
38 MDO4000 Series Specifications and Performance Verification
