Field or control Description
A, B knob controls Use the A knob to select (highlight) the digit(s) to change.
Use the B knob to change the value of the digit(s).
Copy Trigger Settings to
Search
Sets the search criteria to match the current oscilloscope trigger settings.
Copy Search Settings to
Trigger
Sets the current oscilloscope trigger settings to match the search criteria.
I2C serial bus search configuration menu
Use the I2C Search configuration menu to define conditions to search for and mark on an I2C bus waveform. You can have
multiple searches on the same bus.
NOTE. Requires option SREMBD.
Field or control Description
Display Enables or disables displaying search marks on this search.
Stop Acquisition if Event
Found
Stops input acquisition when the search event occurs. Default is not enabled.
Source Select the I
2
C bus that you want to search.
Mark When Select the type of information for which to search.
Direction Sets the transfer direction for which to search.
Only available when Mark When = Address or Address & Data.
Addressing Mode Sets the slave device address length (7 bits or 10 bits long).
Only available when Mark When = Address or Address & Data.
Address Sets the address pattern for which to search. The number of bits shown depends on the
Address Mode setting.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark When = Address or Address & Data.
Data Bytes Sets the number of data bytes for which to search (one to five bytes). Use the A knob to change
the value.
Only available when Mark When = Data or Address & Data.
Data Sets the data pattern for which to search. The number of bits shown depends on the Data
Bytes setting.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark When = Data or Address & Data.
