Operating requirements
Use the oscilloscope within the required operating temperature, power, altitude, and signal input voltage ranges to provide the
most accurate measurements and safe instrument operation.
Environment requirements
Characteristic Description
Operating temperature 0 °C to +50 °C (+32 °F to +122 °F)
For proper cooling, keep the sides and rear of the instrument clear of obstructions for
2 inches (51 mm).
Operating humidity 5% to 90% relative humidity (% RH) up to +40 °C (+104 °F), Noncondensing.
5% to 55% RH above +40 °C up to +50 °C (+104 °F to +122 °F), Noncondensing.
Operating altitude Up to 3000 meters (9842 feet)
Power requirements
Characteristic Description
Power source voltage 100 V - 240 V
AC RMS
, ±10%, single phase
Power source frequency 50/60 Hz, 100-240 V
400 Hz, 115 V
Power consumption All models: 400 W maximum
Input signal requirements
Keep the input signals within allowed limits to ensure the most accurate measurements and prevent damage to the analog and
digital probes or instrument.
Make sure that input signals are within the following requirements.
Input Description
Analog input channels, 1 M Ω setting, maximum
input voltage at BNC
300 V
RMS
Measurement Category II
Analog input channels, 50 Ω setting, maximum
input voltage at BNC
5 V
RMS
Digital input channels, maximum input voltage
range at digital inputs
Observe probe ratings
TLP058; ±42 V
P
Ref In maximum input voltage at BNC (rear panel) 7 V
PP
AUX trigger input ±5 V
RMS
Install your instrument
MSO54, MSO56, MSO58, MSO58LP, MSO64 Help 25
