Field or control Description
Endpoint Sets the token packet endpoint pattern for which to search. Use in conjunction with the Mark
When field to specify the exact search condition. Tap the Binary, Hex, or Decimal field and use
the A and B knobs to select and change the values. Or double-tap on the field and use the
virtual keypad to enter values.
Only available when Mark On = Token Packet and Token Type = all except SOF (0101).
Frame Number Sets the frame number pattern for which to search. Use in conjunction with the Mark When field
to specify the exact search condition.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Token Packet and Token Type = SOF (0101).
Data Packet Type Sets the data packet type for which to search.
Only available when Mark On = Data Packet.
Data Bytes Sets the number of data bytes for which to search (one to sixteen bytes). Tap the field and use
the A knob to change the value.
Only available when Mark On = Data Packet.
Byte Offset Sets the byte offset (Don't Care or the number of bytes). Tap the field and use the A knob to
change the value.
Only available when Mark On = Data Packet.
Data Sets the data packet pattern for which to search. The number of bits shown depends on the
Data Bytes setting. Use in conjunction with the Mark When field to specify the exact search
condition.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Data Packet.
Mark When Sets the mark when condition.
When set to Inside Range or Outside Range, fields are displayed to set a high and low
boundary pattern for the specified search range.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Token Packet or Data Packet.
A, B knob controls Use the A knob to select (highlight) the digit(s) to change.
Use the B knob to change the value of the digit(s).
Copy Trigger Settings to
Search
Sets the search criteria to match the current oscilloscope trigger settings.
Copy Search Settings to
Trigger
Sets the current oscilloscope trigger settings to match the search criteria.
Menus and dialog boxes
MSO54, MSO56, MSO58, MSO58LP, MSO64 Help 249
