Tektronix MSO56B Printable Help

Field or control Description
Data Bytes Sets the number of data bytes on which to trigger. Tap the field and use the A knob to change
the value. Or double-tap on the field and use the virtual keypad to enter a value.
Available when Trigger On = Extended Register Read, Extended Register Write, Ext.
Register Read Long, or Ext. Register Write Long.
No Response Sets to trigger on data that is all zeros (no response). All values in the Data field are set to zero
and cannot be edited.
Available when Trigger On = Master Read, Register Read, Extended Register Read, Ext.
Register Read Long, DD Block Master Read, DD Block Slave Read, or Transfer Bus
Ownership.
Menus and dialog boxes
MSO54, MSO56, MSO58, MSO58LP, MSO64 Help 373
