Maintenance
This section contains the information needed to do periodic and corrective
maintenance on the oscilloscope, and repackaging instructions for returning the
oscilloscope to Tektronix for service.
Preventing
ESD
Before servicing this product, read the General Safety Summary and the Service
Safety Summary at the front of the manual, and familiarize yourself with the
following
electrostatic discharge (ESD) information.
CAUTION. Static discharge can damage any semiconductor component in this
oscilloscope.
When per
forming any service that requires internal access to the oscilloscope,
adhere to the following precautions to avoid damaging internal modules and their
components due to electrostatic discharge:
1. Minimize handling of static-sensitive circuit boards and components.
2. Trans
port and store static-sensitive modules in their s tatic protected containers
or on a metal rail. Label any package that contains static-sensitive boards.
3. Disc
harge the static voltage from your body by wearing a grounded antistatic
wrist strap while handling these modules. Service static-sensitive modules
only at a static-free work station.
4. Do not place anything capable of generating or holding a static charge on the
work station surface.
5. Handle circuit boards by the edges when possible.
6. Do
not slide the circuit boards over any surface.
7. Avoid handling circuit boards in areas that have a floor or work-surface
c
overing capable of generating a static charge.
Inspection and cleaning
Inspection and clea ning are done as preventive maintenance. Pre ventive
maintenance, when done regularly, may prevent oscilloscope malfunction and
enhance its reliability.
Preventive maintenance consists of visually inspecting and cleaning the
oscilloscope and using general care when operating it.
TBS2000 Series Service Manual 4–1
