Tektronix TBS2000 Series Service Manual

Replaceable parts list
Table 5-2: Four
-channel model parts: inputs, main board, power supply, I/O, rear chassis, rear cover
Fig. &
index
number
Tektronix
part num ber
Serial
no.
effective
Serial no.
discont’d Qty
1
Name & description
5-2-1 174-6877-xx 1
CABLE POWER SUPPLY W ITH MAIN BOARD, SAFETY CONTROLLED
-2 211-1272-xx 43
2
SCREW, MACHINE; 6-32 X 0.250, PNH, STL, ZNPL, T-15 TORX DR
-3 119-8488-xx 1
POWER SUPPLY; AC-DC, INTERNAL; 90-264 VAC 47-63 HZ, 103-127 VAC 360-440 HZ IN;
+12V 5A4, 65W OUT; SAFETY CONTROLLED
-4 174-6699-xx 1
CABLE CONNECTION, FRONT-PANEL & MAIN BOARD
-5
146-0148-xx 1
BATTERY, DRY: 3 VOLT, 150MAH, LITHIUM, LEADED BUTTON CELL, SAFETY
CONTROLLED
-6 174-6286-xx 1
CABLE ASSEMBLY (LINE INPUT), SAFETY CONTROLLED
-7
131-6643-xx 2
CONTACT, ELECTRICAL
-8 441-2847-xx 1
CHASSIS; REAR, SAFETY CONTROLLED
-9 119-7086-xx 1
FILTER, EMI; AC LINE CONNECTOR/INPUT FILTER; 6.0A, 120-250VAC, DC-400 HZ
-10 211-0718-xx 2
SCREW, MACHINE; 6-32 X 0.312, FLH100, STEEL, ZINC FINISH, T-10 TORX DR
-11 202-0544-xx 1
CASE, REAR, SAFETY CONTROLLED
-12 367-0598-xx 1
HANDLE, CARRYING OVERMOLDED, SAFETY CONTROLLED
-13 214-5148-xx 2
SPRING FRONT FOOT
-14 348-1909-xx 2
FOOT REAR
-15 348-2222-xx 2
FOOT, FRONT CABINET, HINGED
-16 335-3427-xx 1
LABEL, IO (REAR)
-17 348-2082-xx 4
GROMMET, FAN MOUNT, NOISE DAMPING
-18 119-8751-xx 1
FAN, TUBE AXIAL (92MM, DC, ASSEMBLY)
-19 878-1137-xx 1
CIRCUIT BOARD (IO BOARD)
-20 870-1169-xx 1
CIRCUIT BOARD MAIN BOARD
-21 129-1693-xx 1
3
SCREW, JACK, 433H, 6-32 INTERNAL, 8-32 EXTERNAL
-22 878-1139-xx 1
CIRCUIT BOARD ASSY, ANALOG FRONT END BOARD,
-23 210-1039-xx 4
WASHER, LOCK INTERNAL TOOTH
-24 220-0265-xx 4
4
NUT, PLAIN, HEX; 0.5-28 X 0.625 HEX, BRS, NKL PL
-N/A
119-8771-xx 1
5
WIFI USB DONGLE FOR TBS
1
Qu
antity indicated is for the entire instrument, not necessarily for items in each image.
2
Tightening torque for 211-1272-xx and 211-1273-xx is 0.9 N*M.
3
Tightening torque for 129-1693-xx is 1.13 N*M.
4
Tightening torque for 220-0265-xx is 4.52N*M, ±0.23 N*M.
5
Tektronix option TEKUSBWIFI.
5–6 TBS2000 Series Service Manual
