Tektronix TBS2000 Series Service Manual

Replaceable parts list
Table 5-1: Four
-channel model parts: front panel, display, and front chassis
Fig. &
index
number
Tektronix
part
number
Serial
no.
effective
Serial no.
discont’d Qty
1
Name & description
335-3552-xx 1
LABEL, BLACK FRAME-B4 9 INCH DISPLAY, TBS2074, SAFETY CONTROLLED
5-1-1
335-3553-xx 1
LABEL, BLACK FRAME-B4 9 INCH DISPLAY, TBS2104, SAFETY CONTROLLED
-2 202-0522-xx 1
FRONT CASE
-3 260-3035-xx 1
SWITCH, KEYPAD, ELASTOMERIC POWER; SAFETY CONTROLLED
-4 878-1179-xx 1
CIRCUIT BOARD ASSY; POWER SWITCH BOARD
-5
131-8139-xx 8
CONTACT, SPRING; FRONT PANEL ELEC
-6 211-1273-xx 22
2
SCREW, PT; K35-1.57, PAN HEAD, STL, ZNPL, T-15
-7
850-0312-xx 1
FRAME ASSEMBLY; DISPLAY; TBS2K
-8 407-5760-xx 1
BRACKET, DISPLAY MOUNT
-9 441-2848-xx 1
CHASSIS, FRONT
-10 211-1272-xx 43
2
SCREW, MACHINE; 6-32 X 0.250, PNH, STL, ZNPL,T-15 TORX DR
-11 131-6643-xx 6
CONTACT, ELECTRICAL
-12 174-5411-xx 1
CABLE EXTENSION, USB-HOST
-13 174-6623-xx 1
CABLE, DISPLAY, FFC, 50POS
-14 878-1172-xx 1
PCB, FRONT-PANEL
-15 260-3035-xx 1
SWITCH, KEYPAD, ASSEMBLY FRONT
-16 174-6696-xx 1
CABLE CONNECTION, FRONT-PANEL & POWER SWITCH
335-3428-xx 1
MARKER, IDENTIFICATION LABEL, SAFETY CONTROLLED
335-3728-xx 1
MARKER, IDENTIFICATION FRONT PANEL OVERLAY, KOREAN
335-3744-xx 1
MARKER, IDENTIFICATION FRONT PANEL OVERLAY, FRENCH
335-3745-xx 1
MARKER, IDENTIFICATION FRONT PANEL OVERLAY, RUSSIAN
335-3746-xx 1
MARKER, IDENTIFICATION FRONT PANEL OVERLAY, ITALIAN
335-3747-xx 1
MARKER, IDENTIFICATION FRONT PANEL OVERLAY, GERMAN
335-3748-xx 1
MARKER, IDENTIFICATION FRONT PANEL OVERLAY, SPANISH
335-3749-xx 1
MARKER, IDENTIFICATION FRONT PANEL OVERLAY, JAPANESE
335-3750-xx 1
MARKER, IDENTIFICATION FRONT PANEL OVERLAY, PORTUGUESE
335-3751-xx 1
MARKER, IDENTIFICATION FRONT PANEL OVERLAY, SIMPLE CHINESE
-17
335-3752-xx 1
MARKER, IDENTIFICATION FRONT PANEL OVERLAY, STANDARD CHINESE
-18 366-0935-xx
5
ASSEMBLY, KNOB; .685 DIAMETER
-19 366-0934-xx 6
ASSEMBLY, KNOB; .470 DIAMETER
-20 366-0936-xx 1
ASSEMBLY, KNOB; .925 DIAMETER
-21 335-3429-xx 1
MARKER, IDENTIFICATION LABEL, SAFETY CONTROLLED
1
Quantity indica ted is for the entire instrument, not necessarily for each image.
2
Tightening torque for 211-1272-xx and 211-1273-xx is 0.9 N*M
5–4 TBS2000 Series Service Manual
