Tektronix TBS2000 Series Service Manual

Replaceable parts list
Table 5-3: Two c
hannel model parts; front panel, labels, front panel, LCD, chassis
Fig. &
index
number
Tektronix
part
number
Serial
no.
effective
Serial no.
discont’d Qty
1
Name & description
335-3550-xx 1
LABEL, BLACK FRAME-B2 9 INCH DISPLAY, TBS2102, SAFETY CONTROLLED
5-3-1
335-3546-xx 1
LABEL, BLACK FRAME-B2 9 INCH DISPLAY, TBS2072, SAFETY CONTROLLED
-2 202-0527-xx 1
B2 FRONT CASE SAFETY CONTROLLED
-3 850-0312-xx 1
FRAME ASSEMBLY; DISPLAY; TBS2K
-4 407-5760-xx 1
BRACKET, DISPLAY MOUNT
-5
441-2844-xx 1
CHASSIS, MAIN, SAFETY CONTROLLED
-6 211-1273-xx 22
2
SCREW,PT; K35-1.57, PAN HEAD, STL, ZNPL, T-15
-7
211-1272-xx 43
2
SCREW, MACHINE; 6-32 X 0.250, PNH, STL, ZNPL, T-15 TORX DR
-8 174-6941-xx 1
CABLE, DISPLAY, FFC, 50POS
-9 174-5411-xx 1
CABLE EXTENSION, USB-HOST
-10 131-8139-xx
7
CONTACT, SPRING; FRONT PANEL ELEC
-11 878-1161-xx 1
FRONT PANEL B2 BOARD
-12 260-3038-xx 1
SWITCH, KEYPAD, ELASTOMERIC FRONT PANEL
335-3473-xx 1
MARKER, IDENTIFICATION LABEL FRONT PANEL, 2CH, SA, SAFETY CONTROLLED
335-3729-xx 1
MARKER, IDENTIFICATION FRONT PANEL OVERLAY, FRENCH
335-3730-xx 1
MARKER, IDENTIFICATION FRONT PANEL OVERLAY, RUSSIAN
335-3731-xx 1
MARKER, IDENTIFICATION FRONT PANEL OVERLAY, ITALIAN
335-3732-xx 1
MARKER, IDENTIFICATION FRONT PANEL OVERLAY, GERMANY
335-3733-xx 1
MARKER, IDENTIFICATION FRONT PANEL OVERLAY, SPANISH
335-3734-xx 1
MARKER, IDENTIFICATION FRONT PANEL OVERLAY, JAPANESE
335-3735-xx 1
MARKER, IDENTIFICATION FRONT PANEL OVERLAY, PORTUGUESE
335-3736-xx 1
MARKER, IDENTIFICATION FRONT PANEL OVERLAY, SIMPLE CHINESE
335-3737-xx 1
MARKER, IDENTIFICATION FRONT PANEL OVERLAY, STANDARD CHINESE
-13
335-3738-xx 1
MARKER, IDENTIFICATION FRONT PANEL OVERLAY, KOREAN
-14 366-0935-xx 3
ASSEMBLY, KNOB; .685 IN DIAMETER
-15 366-0934-xx 4
ASSEMBLY, KNOB; .470 IN DIAMETER
-16 366-0936-xx 1
ASSEMBLY, KNOB; .925 IN DIAMETER
1
Quantity indicated is for the entire instrument, n ot necessarily for items in each image.
2
Tightening torque for 211-1272-xx and 211-1273-xx is 0.9 N*M.
5–8 TBS2000 Series Service Manual
