Replaceable parts list
Table 5-4: Two c
hannel model parts; power supply, main board, AC connector/filter, rear cover
Fig. &
index
number
Tektronix
part num ber
Serial
no.
effective
Serial no.
discont’d Qty
1
Name & description
5-4-1 1198-488-xx 1
POWER SUPPLY; AC-DC, INTERNAL; 90-264 VAC 47-63 HZ, 103-127 VAC, 360-440 HZ
IN; +12V 5A4, 65W OUT; SAFETY CONTROLLED
-2 211-1272-xx 43
2
SCREW, MACHINE; 6-32 X 0.250, PNH, STL, ZNPL, T-15 TORX DR
-3 174-6877-xx 1
CABLE POWER SUPPLY W ITH MAIN BOARD, SAFETY CONTROLLED
-4 174-6920-xx 1
CABLE ASSEMBLY (LINE INPUT), SAFETY CONTROLLED
-5
407-5916-xx 1
BRACKET, FILTER, SAFETY CONTROLLED
-6 119-7086-xx 1
FILTER, EMI; AC LINE CONNECTOR/INPUT FILTER; 6.0A, 120-250 VAC, DC-400 HZ
-7
211-0718-xx 2
SCREW, MACHINE; 6-32 X 0.312, FLH100, STEEL, ZINC FINISH, T-10 TORX DR
-8 202-0528-xx 1
CASE, REAR, SAFETY CONTROLLED
-9 367-0598-xx 1
HANDLE, CARRYING OVERMOLDED, SAFETY CONTROLLED
-10 348-1909-xx 2
FOOT REAR; SAFETY CONTROLLED
-11 348-2209-xx 2
FOOT, FRONT CABINET, HINGED, SAFETY CONTROLLED
-12 214-5148-xx 2
SPRING FRONT FOOT
-13 131-6643-xx 4
CONTACT, ELECTRICAL
-14 220-0265-xx 3
3
NUT, PLAIN, HEX; 0.5-28 X 0.625 HEX, BRS, NKL PL
-15 210-1039-xx 3
WASHER, LOCK INTERNAL TOOTH
-16 407-5915-xx 1
BRACKET, REAR BNC IN MAIN BOARD
-17 211-1273-xx 6
SCREW, PT; K35-1.57, PAN HEAD, STL, ZNPL, T-15
-18 870-1175-xx 1
CIRCUIT BOARD ASSY; MAIN B2 BOARD
-19 174-6699-xx 1
CABLE CONNECTION, FRONT- PANEL & MAIN BOARD
-20 253-0571-xx 1
THERMAL INTERFACE MATERIAL SQUARE, 27X27MM
-21 253-0570-xx 1
THERMAL INTERFACE MATERIAL SQUARE, 15X15MM
-22 146-0148-xx 1
BATTERY, DRY: 3 VOLT, 150MAH, LITHIUM, LEADED BUTTON CELL, SAFETY
CONTROLLED
-N/A
119-8771-xx 1
4
WIFI USB DONGLE FOR TBS
1
Qua
ntity indicated is for the entire instrument, not necessarily f or each image.
2
Tightening torque for 211-1272-xx and 211-1273-xx is 0.9 N*M.
3
Tightening torque for 220-0265-xx is 4.52N*M, ±0.23 N*M.
4
Tektronix option TEKUSBWIFI.
5–10 TBS2000 Series Service Manual
