Replaceable parts list
and meet the sam
efactoryspecifications. For more information about the module
exchange program, call 1-800-833-9200, extension 2.
Module repair and return. You may ship your module to us for repair, after which
we will return it to you.
New modules
. You may purchase replacement modules similarly as other
replacement parts.
Using the replaceable parts list
This section contains a list of the mechanical and/or electrical components that
are replaceable for the instrument. Use this list to identify and order replacement
parts. The following table describes each column in the parts list.
Parts list column descriptions
Column Column n
ame
Descrip
tion
1
Figure
& Index
Number
Items i
n this section are referenced by figure and index numbers to the exploded view
illustrations.
2Tektr
onix Part
Number
Use this part number when ordering replacement parts from Tektronix.
3 and 4
Serial Number Column three indicates the serial number at which the part was first effective. Column four
indicates the serial number at which the par t was discontinued. No entries indicates the
part
is good for all serial numbers.
5
Qty This
indicates the quantity of parts used.
6
Nam
e & Description
An i
tem name is separated from the description by a colon (:). Because of space limitations,
an item name m ay sometimes appear as incomplete. U se the U.S. Federal Catalog handbook
H6-1 for further item name identification.
Abbreviations
Abbreviations conform to American N ational Standard ANSI Y1.1-1972.
Exploded views
The illustrations in this section show the module-level exploded views of the
o
scilloscopes. Each exploded view is indexed by the numbers in the figure. The
table of index numbers and part numbers c orresponding to a picture are in the
table immediately proceeding the illustration.
5–2 TBS2000 Series Service Manual
