Tektronix TCP303 Service Manual

Current Probes Replaceable Parts
Table 43: TCP30
3 replaceable parts list
Fig. &
Index
Number
Tektronix
Part Number
Serial
Number
Effective
Serial
Number
Discont’d Qty Name & Description
42-1 204-0713-XX 1
BODY HALF,PROBE:LEFT W/CONTACTS
-2 351-0955-XX 1
SLIDE ASSEMBLY:WITH WARNING LABEL
-3 335-0912-XX 1
MARKER,IDENT:PROBE ID LABEL,TCP303
-4 214-2422-XX 1
SPRING,FLAT:UPPER CAN
-5
050-3663-XX
1
B010000 B019999 1
TRANSFORMER:SUBASSEMBLY, TOP AND BOTTOM, TCP303
120-2028-XX B020000 1
TRANSFORMER:SUBASSEMBLY, TOP AND BOTTOM, TCP303
-6 204-0712-XX 1
BODY HALF,PROBE:RIGHT W/CONTACTS
-7
211-0093-XX 6
SCREW,CAP:4-40 X 0.75,SCH,STL,CD PL,HEX REC
-8 348-0023-XX 4
PLUG,HOLE:U/W0.14 DIA HOLE,WHT PLSTC
-9 211-0183-XX 2
SCREW,CAP:4-40 X 0.5,SCH,STL,CD PL,HEX REC
-10 050-3663-XX
1
B010000 B019999 1
PROBE SUBASSY, TESTED BOARD AND CABLE, TCP303
174-4962-XX B020000 1
CABLE ASSEMBLY, TCP303, RF, COAX, 12 COND, JBX CONNECTOR,
SAFETY CONTROLLED, W/LEMO CONNECTOR
-11 050-3663-XX
1
B010000 B019999 1
PROBE SUBASSY, TESTED BOARD AND CABLE, TCP303
679-6287-XX B020000 1
CIRCUIT BOARD ASSEMBLY, TCP303
-12 214-2446-XX 1
SPR,HLCL,TRSN:0.1 OD X 0.5 L,MUSIC WIRE
-13 367-0218-XX 1
HANDLE,SQUEEZE:PROBE P6301
-14 401-0352-XX 1
GR CLUSTER,SPUR:(2)18 AND (1) 24 T,PLASTIC
-15 343-0149-XX 1
STRAP, TIEDOWN,E,6.75L,PLASTIC
Standard Accessories
-16 016-1924-XX 1
COVER,PROBE,LARGE
071-1185-XX 1
INSTRUCTION SHEET,TCP300/400 SERIES CURRENT PROBES
1
TCP303 probes with S/N B010000 - B019999: The original transformer and cable/circuit board subassemblies must be replaced as a set. (Order Replacement
Kit Number 050-3663-XX.) This kit updates the probe to the equivalent of a serial number B020000 and above, allowing the separate components to
be replaced in the future.
