Preface

This Service Manual supports the basic maintenance of the TCPA300 and

TCPA400 Current Probe Ampliﬁers, and the TCP300/400 Series AC/DC current

probes that m

ate with the ampliﬁers. The current probes covered in this manual

are listed below:

TCP312 (30 A

, 100 MHz, compatible with TCPA 300)

TCP305 (50 A, 50 MHz, compatible with TCPA300)

TCP303 (150 A, 15 MHz, compatible with TCPA300)

TCP404XL (500 A*, 2 MHz, compatible with TCPA400)

*750 A DC derated with duty cycle

If you are not familiar with these products, please refer to the Getting Started and

Operating Basics chapters of the user manual (077-1183-XX) for basic operating

information.

If you are an advanced user, the Reference section in the user manual

contains information on advanced applications as well as user diagnostic and

troub

leshooting information.

The Performance Veriﬁcation and Adjustment Procedure sections in this manual

supp

ort the qualiﬁcation and calibration of the probes when used with either

ampliﬁer.

The

Maintenance in this manual section supports the routine maintenance and

repair of mechanical parts associated with the ampliﬁers.

The

Glossary and Index are provided as quick reference locators for important

information.

Manual Conventions

The term " ampliﬁer" is used to refer to either the TCPA300 or TCPA400 when

referring to common attributes. If a subject is unique to either ampliﬁer, the

ampliﬁer will be referred to directly by model.

The terms "current probe" and "probe" are used to refer to any of the TCP300/400

Series current probes when referring to common a ttributes. If a subject is unique

to a particular probe, the probe will be referred to directly by model.

TCPA300/400 Ampliﬁers and TCP300/400 Series Current Probes Service Manual xv
