Tektronix TDS 200-Series User Manual

Appendix A: Specifications
92
TDS 200-Series Digital Oscilloscope User Manual
Specifications (Cont.)
Input Impedance,
DC Coupled,
EXT TRIG only
TDS 210 (B099188 to B119999
and C021679 to C029999) and
TDS 220 (B065810 to B079999
and C021127 to C029999)
All other TDS 210, TDS 220,
and TDS 224
1.2 MW ±5% in parallel with
20 pF ±5 pF
1 MW ±5% in parallel with
20 pF ±5 pF
P2100 Probe
Attenuation
1X, 10X
Probe Attenuation
Factors
1X, 10X, 100X, 1000X
Maximum Voltage Overvoltage Category Maximum Voltage
Between Signal and
Common at input BNC
CAT I and CAT II
300 V
RMS
(420 V peak, duty
factor < 50%, pulse width
< 100 msec.)
CAT III 150 V
RMS
For steady-state sinusoidal waveforms, derate at 20 dB/decade
above 100 kHz to 13 V
pk
at 3 MHz* and above. Also, refer to
Overvoltage Category description on page 102.
Maximum Voltage Overvoltage Category Maximum Voltage
Between Probe Tip and
ground using P2100
probe connected to
CAT I and CAT II
300 V
RMS
(500 V peak, duty
factor < 35%, pulse width
< 100 msec.)
input BNC
CAT III
100 V
RMS
Derate at 20 dB/decade above 900 kHz to 13 V
RMS
at 27 MHz*
and above. Also, refer to Overvoltage Category description on
page 102.
Time delay between
channels, typical
150 ps
* Bandwidth is not valid for the P2100 probe when the switch is set to 1X.
