Tektronix TDS 200-Series User Manual

Appendix A: Specifications
TDS 200-Series Digital Oscilloscope User Manual
95
Specifications (Cont.)
Vertical
Delta Volts Measure-
ment Accuracy, Aver-
age Acquisition Mode
Delta volts between any two
averages of ≥ 16 waveforms
acquired under same setup
and ambient conditions
±(3% × reading + 0.05 div)
P2100 passive probe
10X position 1X position
Bandwidth DC to 100 MHz DC to 7 MHz
Attenuation ratio 10:1 1:1
Compensation Range 18 pf-35 pf
All oscilloscopes with 1 M W
input
Input resistance
10 M W ± 2% 1MW ± 2%
Input capacitance 14.5 pf-17.5 pf 80 pf-110 pf
Maximum input
voltage
10X position
300 V
RMS
CAT I or 300 V DC CAT I
300 V
RMS
CAT II or 300 V DC CAT II
100 V
RMS
CAT III or 100 V DC CAT III
1X position
150 V
RMS
CAT I or 150 V DC CAT I
150 V
RMS
CAT II or 150 V DC CAT II
100 V
RMS
CAT III or 100 V DC CAT III
