Tektronix TDS 200-Series User Manual

Appendix A: Specifications
96
TDS 200-Series Digital Oscilloscope User Manual
Horizontal
Sample Rate Range
50 S/s to 1 GS/s
Waveform Interpolation (sin x)/x
Record Length 2500 samples for each channel
SEC/DIV Range 5 ns/div to 5 s/div, in a 1, 2.5, 5 sequence
Sample Rate and
Delay Time Accuracy
±100 ppm over any ≥1 ms time interval
Delta Time Measure- Conditions Accuracy
ment Accuracy (Full
Bandwidth)
Single-shot, Sample mode
±(1 sample interval + 100 ppm
× reading + 0.6 ns)
> 16 averages ±(1 sample interval + 100 ppm
× reading + 0.4 ns)
Sample interval = s/div B 250
Position Range 5 ns/div to 10 ns/div (–4 div × s/div) to 20 ms
25 ns/div to 100 ms/div
(–4 div × s/div) to 50 ms
250 ms/div to 5 s/div
(–4 div × s/div) to 50 s

Tektronix TDS 200-Series Specifications
