Appendix A: Specifications
TDS 200-Series Digital Oscilloscope User Manual
99
General Specifications
Display
Display Type 5.7 in. (145 mm) diagonal liquid crystal
Display Resolution 320 horizontal by 240 vertical pixels
Display Contrast Adjustable, temperature compensated
Backlight Intensity,
typical
60 cd/m
2
Probe Compensator Output
Output Voltage, typical
5 V into ≥ 1 MW load
Frequency, typical 1 kHz
Power Source
Source Voltage 100 – 120 VAC
RMS
(" 10%) from 45 Hz through 440 Hz, CAT II
120 – 240 VAC
RMS
(" 10%) from 45 Hz through 66 Hz, CAT II
Power Consumption TDS 210 and TDS 220 TDS 224
Less than 20 W Less than 25 W
Fuse 1 A, T rating, 250 V
Environmental
Temperature Operating 0° C to +50° C
Nonoperating –20° C to +60° C
Cooling Method Convection
Humidity +40° C or below ≤ 90% relative humidity
+41° C to +50° C ≤ 60% relative humidity
Altitude Operating 3,000 m
Nonoperating 15,000 m
