Tektronix TDS 200-Series User Manual

Appendix A: Specifications
98
TDS 200-Series Digital Oscilloscope User Manual
Specifications (Cont.)
Trigger
Trigger Level Accuracy, Accuracies are for signals having rise and fall times ≥ 20 ns
typical
Source
Accuracy
Internal ±0.2 div volts/div within ±4 divisions from
center screen
TDS 210 and TDS 220 only
EXT ±(6% of setting + 40 mV)
EXT/5 ±(6% of setting + 200 mV)
SET LEVEL TO 50%,
typical
Operates with input signals ≥ 50 Hz
Default Settings, Video
Trigger
Trigger mode is Auto and Coupling is AC
Sensitivity, Video Composite video signal
Trigger Type, typical
Source
Range
Internal Pk-pk amplitude of 2 divisions
TDS 210 and TDS 220 only
EXT 400 mV
EXT/5 2 V
Signal Formats and
Field Rates, Video
Trigger Type
Supports NTSC, PAL, and SECAM broadcast systems for any
field or any line
Holdoff Range 500 ns to 10 s
Measurements
Cursors
Voltage difference between cursors (DV)
Time difference between cursors (DT)
Reciprocal of DT in Hertz (1/DT)
Automated Measure-
ments
Cycle RMS, Mean, Pk – Pk, Period, Frequency
