Tektronix TDS1002 Programmer's Manual

Status and Events
TDS200/1000/2000 Series Oscilloscope Programmer Manual
3−9
Device Event Status Enable Register
(DESER)
Standard Event Status Register
(SESR)
Event Status Enable Register
(ESER)
Status Byte Register
(SBR)
Service Request Enable Register
(SRER)
Event
Queue
Output
Queue
Event
Event
Event
Byte
Byte
Byte
1
2
3
4
67
5
PON URQ CME EXE DDE QYE RQC OPC
76543210
PON URQ CME EXE DDE QYE RQC OPC
76543210
PON URQ CME EXE DDE QYE RQC OPC
76543210

RQS
ESBMAV
MSS
7
6
543210
6
ESBMAV
76543210
Read using DESE?
Write using DESE
Read using *ESR?
Cannot be written
Read using *ESE?
Write using *ESE
Read using *STB?
Cannot be written
Read using *SRE?
Write using *SRE
Figure 3−6: Status and event handling process

Tektronix TDS1002 Specifications

General

Bandwidth	60 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Display Resolution	320 x 240 pixels
Display	5.7 inch monochrome LCD
Trigger Modes	Video, Edge
Connectivity	USB 2.0
Weight	2.0 kg
Input Impedance	1 MΩ
Power Supply	100 to 240 VAC, 45 to 440 Hz
