Tektronix TDS1002 Programmer's Manual

Command Groups
TDS200/1000/2000 Series Oscilloscope Programmer Manual
2−29
Table 2−21: Waveform commands (Cont.)
Header Description
WFMPre:YOFf Set/query the vertical offset
WFMPre:YUNit Set/query the vertical units
WFMPre:YZEro?
1
Set/query the waveform conversion factor
WFMPre:<wfm>? Returns waveform formatting data
WFMPre:<wfm>:PT_Fmt Set/query the format of curve points
WFMPre:<wfm>:PT_Off? Query the trigger offset
WFMPre:<wfm>:WFId? Query the waveform identifier
WFMPre:<wfm>:XINcr Set/query the horizontal sampling interval
WFMPre:<wfm>:XUNit Set/query the horizontal units
WFMPre:<wfm>:XZEro Set/query the time of first datapoint in
waveform
WFMPre:<wfm>:YMUlt Set/query the vertical scale factor
WFMPre:<wfm>:YOFf Set/query the vertical position
WFMPre:<wfm>:YUNit Set/query the vertical units
WFMPre:<wfm>:YZEro?
1
Set/query the waveform conversion factor
1
TDS1000 and TDS2000 series, or TDS200 series with a TDS2MM
measurement module.
Waveform Data Formats
Internally, the oscilloscope uses one 8-bit data byte to represent each
waveform data point, regardless of the acquisition mode.
The DATa:WIDth command lets you specify the number of bytes per
data point when transferring data to and from an oscilloscope. This
provides compatibility with other digitizing oscilloscopes.

Tektronix TDS1002 Specifications

General

Bandwidth	60 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Display Resolution	320 x 240 pixels
Display	5.7 inch monochrome LCD
Trigger Modes	Video, Edge
Connectivity	USB 2.0
Weight	2.0 kg
Input Impedance	1 MΩ
Power Supply	100 to 240 VAC, 45 to 440 Hz
