Tektronix TDS1002 Programmer's Manual

Command Groups
2−26
TDS200/1000/2000 Series Oscilloscope Programmer Manual
Table 2−19: Trigger commands (Cont.)
Header Description
TRIGger:MAIn:VIDeo? Query video trigger parameters
TRIGger:MAIn:VIDeo:LINE
1
Set/query video trigger line
TRIGger:MAIn:VIDeo:POLarity Set/query video trigger polarity
TRIGger:MAIn:VIDeo:SOUrce Set/query video trigger source
TRIGger:MAIn:VIDeo:STANdard
1
Set/query video trigger standard
TRIGger:MAIn:VIDeo:SYNC Set/query video trigger sync
TRIGger:STATE? Return trigger system status
1
TDS1000 and TDS2000 series only.
Vertical Commands
Vertical commands control the attributes of the channels. The
SELect:<wfm> command also displays a specified waveform or
removes it from the display. Table 2-20 lists and describes Vertical
commands.
Table 2−20: Vertical commands
Header Description
CH<x>? Return vertical parameters
CH<x>:BANdwidth Set/query channel bandwidth
CH<x>:COUPling Set/query channel coupling
CH<x>:INVert
1
Set/query channel invert
CH<x>:POSition Set/query channel position
CH<x>:PRObe Set/query channel probe parameters
CH<x>:SCAle Set/query channel volts/div

Tektronix TDS1002 Specifications

General

Bandwidth	60 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Display Resolution	320 x 240 pixels
Display	5.7 inch monochrome LCD
Trigger Modes	Video, Edge
Connectivity	USB 2.0
Weight	2.0 kg
Input Impedance	1 MΩ
Power Supply	100 to 240 VAC, 45 to 440 Hz
