Tektronix TDS1002 Programmer's Manual

Status and Events
TDS200/1000/2000 Series Oscilloscope Programmer Manual
3−1 1
MEASUREMENT:IMMED:VALUE?
Processing Time
Acquiring Waveform Data
ACQUIRE:STATE ON
Figure 3−7: Command processing without using synchronization
The acquisition of the waveform must be completed before the
measurement can be taken on the acquired data. This is achieved by
synchronizing the program so that the measurement command is not
processed by the oscilloscope until the acquisition is complete.
Figure 3-8 shows the desired processing sequence.
MEASUREMENT:IMMED:VALUE?
Processing Time
Acquiring Waveform Data
ACQUIRE:STATE ON
Figure 3−8: Processing sequence with synchronization
Four commands can be used to synchronize the operation of the
oscilloscope with your application program: *WAI, BUSY?, *OPC,
and *OPC?. The *OPC? query is the most simple.
Using the *WAI Command
You can force commands to execute sequentially by using the *WAI
command. This command forces completion of the previous
commands before processing new ones.

Tektronix TDS1002 Specifications

General

Bandwidth	60 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Display Resolution	320 x 240 pixels
Display	5.7 inch monochrome LCD
Trigger Modes	Video, Edge
Connectivity	USB 2.0
Weight	2.0 kg
Input Impedance	1 MΩ
Power Supply	100 to 240 VAC, 45 to 440 Hz
