Command Groups
TDS200/1000/2000 Series Oscilloscope Programmer Manual
2−27
Table 2−20: Vertical commands (Cont.)
Header Description
CH<x>:VOLts Same as CH<x>:SCAle
SELect:<wfm> Set/query waveform display state
1
All oscilloscope, firmware version, and module combinations
except TDS210 and TDS220 with firmware below V 2.00 and a
TDS2CMA communications module.
Waveform Commands
Waveform commands let you transfer waveform data points to and
from the oscilloscope. Waveform data points are a collection of
values that define a waveform. One data value usually represents one
data point in the waveform record. When working with peak-detect
waveforms, each data value is either the min or max of a min/max
pair. Before you can transfer waveform data, you must specify the
data format and waveform locations.
Table 2-21 lists and describes Waveform commands. Refer to the
text following this table for more information about waveform
commands.
Table 2−21: Waveform commands
Header Description
CURVe Transfer waveform data to or from the
oscilloscope
DATa Set/query the waveform data format and
location
DATa:DESTination Set/query the destination for waveforms
sent to the oscilloscope
DATa:ENCdg Set/query the waveform data encoding
method
DATa:SOUrce Set/query the source of CURVe? data
