Tektronix TDS1002 Programmer's Manual

Command Syntax
TDS200/1000/2000 Series Oscilloscope Programmer Manual
2−3
Table 2−2: Command message elements (Cont.)
Symbol Meaning
<Argument>
A quantity, quality, restriction, or limit associated with
the header. Not all commands have an argument,
while other commands have multiple arguments.
Arguments are separated from the header by a
<Space>. Arguments are separated from each
other by a <Comma>.
<Comma>
A single comma between arguments of multiple−ar−
gument commands. It may optionally have white
space characters before and after the comma.
<Space>
A white space character between command header
and argument. It may optionally consist of multiple
white space characters.
Figure 2-1 shows the five command message elements.
Comma
SAVe:WAVEform CH1,REFA
Header
Mnemonics Arguments
Space
Figure 2−1: Command message elements

Tektronix TDS1002 Specifications

General

Bandwidth	60 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Display Resolution	320 x 240 pixels
Display	5.7 inch monochrome LCD
Trigger Modes	Video, Edge
Connectivity	USB 2.0
Weight	2.0 kg
Input Impedance	1 MΩ
Power Supply	100 to 240 VAC, 45 to 440 Hz
