Command Groups
TDS200/1000/2000 Series Oscilloscope Programmer Manual
2−21
Table 2−14: Measurement commands (Cont.)
Header Description
MEASUrement:IMMed:VALue? Return the immediate measurement
result
MEASUrement:MEAS<x>? Return parameters on the periodic
measurement
MEASUrement:MEAS<x>:SOUrce Set/query channel to take the periodic
measurement from
MEASUrement:MEAS<x>:TYPe Set/query the type of periodic measure−
ment to be taken
MEASUrement:MEAS<x>:UNIts? Returns the units for periodic measure−
ment
MEASUrement:MEAS<x>:VALue? Returns periodic measurement results
Miscellaneous Commands
Miscellaneous commands are a group of commands that do not fit
into any other category.
Several commands and queries are common to all 488.2–1987
devices on the GPIB BUS and the device on the RS-232 interface.
These commands and queries are defined by IEEE Std. 488.2–1987
and Tek Standard Codes and Formats 1989 and begin with an
asterisk (*) character. Table 2-15 lists and describes Miscellaneous
commands.
Table 2−15: Miscellaneous commands
Header Description
AUTOSet Automatic oscilloscope setup
AUTOSet:SIGNAL?
1
Returns the type of signal found by
autoset
AUTOSet:VIEW
1
Set/query Autoset view

Tektronix TDS1002 Specifications

General

Bandwidth	60 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Display Resolution	320 x 240 pixels
Display	5.7 inch monochrome LCD
Trigger Modes	Video, Edge
Connectivity	USB 2.0
Weight	2.0 kg
Input Impedance	1 MΩ
Power Supply	100 to 240 VAC, 45 to 440 Hz
