Tektronix TDS1002 Programmer's Manual

Command Syntax
2−10
TDS200/1000/2000 Series Oscilloscope Programmer Manual
Symbol Meaning
MEAS<x> A measurement specifier; <x> is 1−4 (TDS200
Series) or 1−5 (TDS1000 and TDS2000 series).
Argument Types
A command argument can be in one of several forms. The individual
descriptions of each command tell which argument types to use with
that command.
Numeric Arguments
Many oscilloscope commands require numeric arguments. Table 2-4
lists the three types of numeric argument.
Table 2−4: Types of numeric arguments
Symbol Meaning
<NR1> Signed integer value
<NR2> Floating point value without an exponent
<NR3> Floating point value with an exponent
The syntax shown is the data format that the oscilloscope returns in
response to a query. This format is also the preferred format when
sending a command to the oscilloscope.
When you enter an incorrect numeric argument, the oscilloscope
automatically forces the numeric argument to a correct value.
Table 2-5 lists how the oscilloscope handles incorrect numeric
arguments.

Tektronix TDS1002 Specifications

General

Bandwidth	60 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Display Resolution	320 x 240 pixels
Display	5.7 inch monochrome LCD
Trigger Modes	Video, Edge
Connectivity	USB 2.0
Weight	2.0 kg
Input Impedance	1 MΩ
Power Supply	100 to 240 VAC, 45 to 440 Hz
