Tektronix TDS1002 Programmer's Manual

Command Syntax
TDS200/1000/2000 Series Oscilloscope Programmer Manual
2−9
Reference Waveform Mnemonics
Commands can specify the reference waveform to use as a
mnemonic in the header.
Symbol Meaning
REF<x> 2−channel models: A reference waveform specifier;
<x> is A or B.
4−channel models: A reference waveform specifier;
<x> is A, B, C, or D.
Waveform Mnemonics
In some commands you can specify a waveform without regard to its
type: channel waveform, math waveform, or reference waveform.
The “y” is the same as “x” in Reference Waveform Mnemonics.
Symbol Meaning
<wfm> Can be CH<x>, MATH, or REF<y>
Cursor Position Mnemonic
When the oscilloscope displays cursors, commands may specify
which cursor of the pair to use.
Symbol Meaning
POSITION<x>
A cursor selector; <x> is 1 or 2.
Measurement Specifier Mnemonics
Commands can specify which measurement to set or query as a
mnemonic in the header. The oscilloscope can display up to four
(TDS200 series) or five (TDS1000 and TDS2000 series) automated
measurements.

Tektronix TDS1002 Specifications

General

Bandwidth	60 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Display Resolution	320 x 240 pixels
Display	5.7 inch monochrome LCD
Trigger Modes	Video, Edge
Connectivity	USB 2.0
Weight	2.0 kg
Input Impedance	1 MΩ
Power Supply	100 to 240 VAC, 45 to 440 Hz
