Tektronix TDS1002 Programmer's Manual

Command Groups
TDS200/1000/2000 Series Oscilloscope Programmer Manual
2−23
Table 2−16: RS−232 commands
Header Description
RS232? Query RS232 parameters
RS232:BAUd Set/query baud rate
RS232:HARDFlagging Set/query hard flagging
RS232:PARity Set/query parity type
RS232:SOFTFlagging Set/query soft flagging
RS232:TRANsmit:TERMinator Set/query end−of−line terminator
Save and Recall Commands
Save and Recall commands allow you to store and retrieve internal
waveforms and settings. When you “save a setting,” you save most
of the settings of the oscilloscope. When you then “recall a setting,”
the oscilloscope restores itself to the state it was in when you saved
that setting.
To display a saved waveform, use the SELect:<wfm> command
described on page 2-134. Table 2-17 lists and describes Save and
Recall commands.
Table 2−17: Save and Recall commands
Header Description
*RCL Recall setting
RECAll:SETUp Recall saved oscilloscope setting
*SAV Save oscilloscope setting
SAVe:SETUp Save oscilloscope setting
SAVe:WAVEform Save waveform

Tektronix TDS1002 Specifications

General

Bandwidth	60 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Display Resolution	320 x 240 pixels
Display	5.7 inch monochrome LCD
Trigger Modes	Video, Edge
Connectivity	USB 2.0
Weight	2.0 kg
Input Impedance	1 MΩ
Power Supply	100 to 240 VAC, 45 to 440 Hz
