Tektronix TDS1002 Programmer's Manual

Command Groups
2−28
TDS200/1000/2000 Series Oscilloscope Programmer Manual
Table 2−21: Waveform commands (Cont.)
Header Description
DATa:STARt Set/query the starting point in waveform
transfer
DATa:STOP Set/query the ending point in waveform
transfer
DATa:TARget Same as DATa:DESTination
DATa:WIDth Set/query the byte width of waveform
points
WAVFrm? Returns waveform preamble and curve
data
WFMPre? Returns waveform preamble
WFMPre:BIT_Nr Set/query the preamble bit width of
waveform points
WFMPre:BN_Fmt Set/query the preamble binary encoding
type
WFMPre:BYT_Nr Set/query the preamble byte width of
waveform points
WFMPre:BYT_Or Set/query the preamble byte order of
waveform points
WFMPre:ENCdg Set/query the preamble encoding method
WFMPre:NR_Pt Query the number of points in the curve
transfer
WFMPre:PT_Fmt Set/query the format of curve points
WFMPre:PT_Off Query the trigger offset
WFMPre:WFId? Query the waveform identifier
WFMPre:XINcr Set/query the horizontal sampling interval
WFMPre:XUNit Set/query the horizontal units
WFMPre:XZEro Set/query time of first point in waveform
WFMPre:YMUlt Set/query the vertical scale factor

Tektronix TDS1002 Specifications

General

Bandwidth	60 MHz
Channels	2
Sample Rate	1 GS/s
Record Length	2.5k points
Vertical Sensitivity	2 mV/div to 5 V/div
Vertical Resolution	8 bits
Display Resolution	320 x 240 pixels
Display	5.7 inch monochrome LCD
Trigger Modes	Video, Edge
Connectivity	USB 2.0
Weight	2.0 kg
Input Impedance	1 MΩ
Power Supply	100 to 240 VAC, 45 to 440 Hz
