Reference
84
TDS1000/2000-Series Digital Oscilloscope User Manual
Cursors
Push the CURSOR button to display the measurement cursors and
Cursor Menu.
Options Settings Comments
Type*
Voltage
Time
Off
Select and display the measurement
cursors; Voltage measures amplitude and
Time measures time and frequency
Source CH1
CH2
CH3**
CH4**
MATH
REFA
REFB
REFC **
REFD **
Choose the waveform on which to take
the cursor measurements
The readouts display this measurement.
Delta Displays the difference (delta) between
the cursors
Cursor 1 Displays cursor 1 location (time is
referenced to the trigger position, voltage
is referenced to ground)
Cursor 2 Displays cursor 2 location (time is
referenced to the trigger position, voltage
is referenced to ground)
* For a Math FFT source, measures magnitude and frequency.
** Available only on 4-channel oscilloscopes.

Tektronix TDS2024 Specifications

General

Channels	4
Bandwidth	200 MHz
Sample Rate	2 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Math Functions	Add, Subtract, Multiply, Divide, FFT
Input Coupling	AC, DC, GND
Trigger Modes	Auto, Normal, Single
Trigger Types	Edge, Video, Pulse
Connectivity	USB
Input Impedance	1 MΩ
Maximum Input Voltage	300 V
Interface	USB
Power Supply	100 to 240 V
Dimensions	326 mm x 158 mm x 124 mm
